BC33725TA

BC33725TA ON Semiconductor Trans GP BJT NPN 45V 0.8A 625mW 3-Pin TO-92 Fan-Fold

ManufacturerON Semiconductor
Series-
PackagingTape & Box (TB)
Part StatusActive
Transistor TypeNPN
Current - Collector (Ic) (Max)800mA
Voltage - Collector Emitter Breakdown (Max)45V
Vce Saturation (Max) @ Ib, Ic700mV @ 50mA, 500mA
Current - Collector Cutoff (Max)100nA
DC Current Gain (hFE) (Min) @ Ic, Vce160 @ 100mA, 1V
Power - Max625mW
Frequency - Transition100MHz
Operating Temperature150°C (TJ)
Mounting TypeThrough Hole
Package / CaseTO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Supplier Device PackageTO-92-3
